P2 small pitch LED display

Features：

1. Using high-quality components and fine processing technology to effectively reduce the dead light rate.
2. Power supply, signal dual backup system, escort for 7*24 hours of continuous and stable operation, the safest and most reliable.
3. The gray scale performance of the display is almost perfect under low brightness, and the display layering and vividness are higher than the traditional display.
4. High pixel density display unit with micro pixel pitch, wireless splicing, capable of supporting 2K, 4K and ultra high resolution display.
5. Even if it is reduced to 500-300 cd/m2, high gradation can be guaranteed.
6. The black matte lamp and the corrugated light-absorbing mask are used to reflect light in a bright environment, and the picture is still clearly visible.
7. Automatically adapt to the light-sensing device without affecting the display due to the environment.
8. The picture is stable, no ripples and no black screen, the video picture is smooth and smooth, and the edges of the dynamic display picture are clear. With good dynamic performance, the image information can be accurately restored to bring the greatest visual enjoyment.

Online Order

P2 small pitch led display parameters

Product number	JH-XJJ-P2	brightness	1300nits	Pixel density	230500
Module size	200*150	Best viewing distance	2m-60m	Average power	350
Pixel spacing	1.2mm	Refresh rate	≥1920	Service life	100,000hour

Golden proportion atmospheric fashion

The ratio of small-diameter led box is 16:9, which is the proportion of pupils in the human eye, the proportion of gold, enjoy the visual, atmospheric fashion.

Ultra HD perfect picture quality

The small pitch led extremely high resolution brings a delicate display effect, and is a beautiful embodiment of the new generation of ultra high definition LED display technology.

Easy to achieve FHD, 4K big screen

The small-pitch led display can be spliced in any size and in any direction. A variety of video sources can be selected to easily realize FHD and 4K large screens.

The bottom is bright and gray, the picture is more delicate

High-quality black LED lights, with a black mask, the contrast ratio of up to 3000:1, making the picture more clear and delicate.

Power signal dual backup

Dual signal input is used to automatically detect the integrity of the signal; dual redundant power supply, when one power supply stops working, another standby power supply continues to supply, without affecting the normal use of the product.

Seamless stitching

With a unique connector, the gap of the cabinet can be fine-tuned to show the perfect picture quality; the mold is molded at one time, and the processing precision is ±0.1mm, which makes it easy to achieve seamless stitching.

P2 small pitch led display application field

Education and publicity: interactive systems such as campus areas and training institutions.
Public places: information display of transportation industries such as airports, railways, subways, highways, libraries, museums, shopping malls, etc.
Commercial presentations: TV studios, large-scale performances, business exhibitions, hotel lobbies, enterprises and institutions.
Government departments: convenience publicity, work guides, government affairs disclosure, etc.

specification	p1.2	P1.5	p1.6	p1.8	p1.9	p2.0	p2.5
Pixel structure	SMD three-in-one	SMD three-in-one	SMD three-in-one	SMD three-in-one	SMD three-in-one	SMD three-in-one	SMD three-in-one
Pixel spacing(mm)	1.25	1.5625	1.667	1.875	1.923	2.0	2.5
Module size(mm)	200*150	200*150	200*150	200*150	200*150	200*150	200*150
Module resolution(W*H)	120*135	128*96	120*96	106*80	104*78	96*72	64*64
Pixel composition	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B
Box size	400*300	400*300	400*300	400*300	400*300	400*300	400*300
Cabinet resolution	480*270	258*192	240*180	212*160	208*156	192*144	192*192
Pixel density(点/m²)	623942	409600	360000	284444	270400	230500	160000
Box material	Die-cast aluminum	Die-cast aluminum	Die-cast aluminum	Die-cast aluminum	Die-cast aluminum	Die-cast aluminum	Die-cast aluminum
Box weightKG	3.8	3.8	3.8	3.8	3.8	3.6	3.6
Screen weightKG	36	36	36	36	36	34	34
Box flatness(mm)	≤0.2mm	≤0.2mm	≤0.2mm	≤0.2mm	≤0.2mm	≤0.2mm	≤0.2mm
Single point brightness correction	Have	Have	Have	Have	Have	Have	Have
Single point color correction	Have	Have	Have	Have	Have	Have	Have
White balance brightness(cd/m²)	≥1200nit(Adjustable)	≥1200nit(Adjustable)	≥1200nit(Adjustable)	≥1200nit(Adjustable)	≥1200nit(Adjustable)	≥1200nit(Adjustable)	≥1200nit(Adjustable)
Gray level(bie)	16	16	16	16	16	16	16
Color temperature(K)	3200K-9300K (Adjustable)	3200K-9300K (Adjustable)	3200K-9300K (Adjustable)	3200K-9300K (Adjustable)	3200K-9300K (Adjustable)	3200K-9300K (Adjustable)	3200K-9300K (Adjustable)
Viewing angle(H/V)	H:160° V:160°	H:160° V:160°	H:160° V:160°	H:160° V:160°	H:160° V:160°	H:160° V:160°	H:160° V:160°
Peak power consumption(W/m²)	120W/Box 1000W/m²	120W/Box 1000W/m²	120W/Box 1000W/m²	120W/Box 1000W/m²	120W/Box 1000W/m²	120W/Box 1000W/m²	120W/Box 1000W/m²
Average power consumption	40W/Box 350W/m²	40W/Box 350W/m²	40W/Box 350W/m²	40W/Box 350W/m²	40W/Box 350W/m²	40W/Box 350W/m²	40W/Box 350W/m²
Power supply requirements	AC110~240V (50/60Hz)	AC110~240V (50/60Hz)	AC110~240V (50/60Hz)	AC110~240V (50/60Hz)	AC110~240V (50/60Hz)	AC110~240V (50/60Hz)	AC110~240V (50/60Hz)
Contrast	6000:1	6000:1	6000:1	6000:1	6000:1	6000:1	6000:1
Picture frame rate(Hz)	≥60	≥60	≥60	≥60	≥60	≥60	≥60
Refresh rate(Hz)	≥1920	≥1920	≥1920	≥1920	≥1920	≥1920	≥1920
Operating temperature(℃)	-20~50	-20~50	-20~50	-20~50	-20~50	-20~50	-20~50
Working humidity(RH)	10~80%No frosting	10~80%No frosting	10~80%No frosting	10~80%No frosting	10~80%No frosting	10~80%No frosting	10~80%No frosting
Storage temperature(℃)	-20-60	-20-60	-20-60	-20-60	-20-60	-20-60	-20-60
Storage humidity(RH)	10~85%No frosting	10~85%No frosting	10~85%No frosting	10~85%No frosting	10~85%No frosting	10~85%No frosting	10~85%No frosting
Service life	100,000hour	100,000hour	100,000hour	100,000hour	100,000hour	100,000hour	100,000hour
Maintenance method	Post maintenance	Post maintenance	Post maintenance	Post maintenance	Post maintenance	Post maintenance	Post maintenance
